LED Illuminated Bathroom Mirror Cabinet
Overview
An LED illuminated mirror cabinet combines a storage compartment with edge‑lit lighting to provide task illumination in wet environments. The unit is designed for wall‑mounted installation in commercial restrooms, hospitality suites, and healthcare facilities where consistent light levels and moisture resistance are required.
Construction Materials
The cabinet frame is fabricated from extruded aluminum alloy 6063‑T5, offering a tensile strength of approximately 210 MPa and corrosion resistance suitable for humid conditions. The mirror panel uses 5 mm tempered glass with a silver backing, meeting EN 12150‑1 standards for impact safety. Interior shelving is made from 12 mm moisture‑resistant MDF coated with a PVC laminate.
- Aluminum frame thickness: 2.0 mm nominal
- Glass edge polishing: flat‑polished with 0.5 mm safety bevel
- Shelf load rating: 15 kg uniformly distributed
LED Illumination Specifications
Edge‑mounted SMD 2835 LEDs provide uniform illumination across the mirror surface. The system delivers a typical illuminance of 350 lux at a distance of 0.5 m from the glass, with a color temperature of 4000 K ± 200 K and a CRI of 90+. Power consumption averages 12 W per linear foot of illuminated edge.
| Parameter | Typical Value | Notes |
|---|---|---|
| Luminous Flux | 800 lm per foot | Measured at LED source |
| Operating Voltage | 24 V DC | Constant‑voltage driver required |
| IP Rating (Light Engine) | IP44 | Protected against splashing water |
| Lifespan (L70) | 50,000 h | At 25 °C ambient |
Electrical and Control Options
The cabinet operates from a isolated 24 V DC power supply, complying with UL 1310 and IEC 61347‑2‑13 standards for LED drivers. Control interfaces include a capacitive touch switch integrated into the lower frame, an optional passive infrared motion sensor with adjustable delay (5 s–30 s), and a low‑voltage 0‑10 V dimming input for building‑management integration.
- Touch switch rating: 10 mA at 24 V DC
- Motion sensor detection range: 1.5 m–3.0 m
- Dimming range: 10 %–100 % without flicker
Dimensions and Mounting
Standard cabinet widths range from 500 mm to 1200 mm in 100 mm increments, with a fixed height of 700 mm and depth of 150 mm (including door protrusion). Mounting is achieved via four concealed zinc‑plated steel brackets that engage with pre‑drilled holes in the frame, allowing for a maximum load of 30 kg per anchor point when installed on concrete or solid masonry.
| Width (mm) | Number of LED Strips | Total Power (W) |
|---|---|---|
| 500 | 1 | 12 |
| 800 | 2 | 24 |
| 1100 | 3 | 36 |
| 1200 | 3 | 36 |
Environmental Ratings
The assembled unit meets IEC 60529 IP44 for the lighting compartment and IP20 for the cabinet interior, ensuring protection against water splashes from any direction while maintaining safe internal electrical isolation. Materials are selected to resist typical bathroom cleaning agents, including diluted sodium hypochlorite (up to 5 %) and ammonia‑based solutions, without degradation of finish or adhesion.
Applications
LED illuminated mirror cabinets are specified in environments where consistent vertical illumination reduces shadows on the face, improving grooming accuracy and user comfort. In healthcare settings, the uniform light supports clinical examinations that require true color rendering. In hospitality installations, the integrated storage minimizes countertop clutter while delivering a premium aesthetic that aligns with brand standards.
- Commercial office restrooms – high‑frequency use, vandal‑resistant mounting
- Spa and wellness centers – moisture‑resistant finishes, low‑glare lighting
- Retail fitting rooms – true‑color rendering for apparel assessment
Quality Assurance
Each production lot undergoes a 100 % visual inspection for glass defects, frame finish uniformity, and LED alignment. Functional testing verifies illuminance uniformity (variance ≤ 15 % across the surface), driver efficiency (> 85 %), and ingress protection via spray testing per IEC 60529. Documentation includes a material traceability record and a conformity declaration referencing the relevant UL and IEC standards.
Customization Options
Beyond standard dimensions, customers may request alternative LED color temperatures (3000 K, 5000 K), adjusted CRI levels (≥ 95), or integrated defogging elements (transparent conductive film with 30 W m⁻² K⁻¹ heating power). Frame finishes can be supplied in anodized black, brushed nickel, or powder‑coated RAL colors to match architectural specifications.
- Custom glass thickness: 4 mm–6 mm tempered
- Alternative shelving: stainless steel grade 304
- Special wiring: conduit‑ready knock‑outs for hard‑install
Frequently Asked Questions
Can the cabinet dimensions be modified to match a specific rough‑in opening?
Yes. Width, height, and depth can be adjusted in 10 mm increments within the structural limits of the aluminum frame and glass thickness. A detailed drawing of the opening is required before quotation.
What information is needed to obtain a firm price and lead time?
Project‑specific inputs include: required overall dimensions, LED color temperature/CRI, control method (touch, motion, dimming), finish selection, quantity, and destination for freight assessment. Lead time typically ranges from 4–6 weeks after drawing approval.
Which materials are available for the frame and shelving?
Frame options: extruded aluminum 6063‑T5 (standard), stainless steel 304 (corrosive environments). Shelving options: moisture‑resistant MDF with PVC laminate, tempered glass, or stainless steel.
