Free Standing Bathroom Vanity Without Top
Free Standing Bathroom Vanity Without Top
This product is a base cabinet designed to support a countertop that is supplied separately. It is intended for wall‑free installation in commercial restrooms, hospitality suites, and high‑traffic healthcare facilities where a separate countertop material (e.g., solid surface, quartz, or stainless steel) is preferred for hygiene or design flexibility.
Design and Construction
The vanity consists of a fully welded steel frame with 1.5 mm thick cold‑rolled steel panels for the sidewalls and a 2.0 mm thick reinforced base rail. All joints are continuous‑welded and ground smooth to eliminate crevices that could harbor moisture or contaminants.
Adjustable leveling feet with a 30 mm travel range and lock‑nuts provide ±5 mm height adjustment to accommodate uneven floor substrates. The feet are made of zinc‑plated steel with a nylon base to prevent floor marking.
- Overall dimensions: 600 mm (W) × 500 mm (D) × 800 mm (H) – customizable in 50 mm increments.
- Drawer configuration: two full‑extension soft‑close drawers, each rated for 30 kg dynamic load.
- Door option: single hinged door with 110° opening angle, concealed European hinge.
Technical Specifications
| Parameter | Typical Value | Notes |
|---|---|---|
| Frame material | Cold‑rolled steel, SPCC | Yield strength ≥ 250 MPa |
| Panel thickness | Sidewalls 1.5 mm, base rail 2.0 mm | All surfaces powder‑coated |
| Load capacity (per drawer) | 30 kg dynamic, 45 kg static | Tested per EN 14749 |
| Finish | Electrostatic powder coat, RAL 9010 (white) or custom | Film thickness 60–80 µm, UV stable |
| Leveling feet travel | 30 mm | Lock‑nut secures position |
Material Options
- Frame: SPCC cold‑rolled steel (standard) or stainless steel 304 for corrosive environments.
- Finish: Powder coat (standard RAL colors), anti‑microbial coating, or brushed stainless.
- Drawer slides: Ball‑bearing, full‑extension, soft‑close, rated 30 kg.
- Hinges: Concealed European, 110° opening, nickel‑plated.
Applications
In hospitality guest rooms, the vanity base provides storage for toiletries and allows the countertop to be selected independently to match the interior design.
In healthcare settings, the seamless welded construction eliminates crevices that can harbor contaminants, and an optional anti‑microbial powder coat can be applied. The open base allows floor cleaning beneath the unit.
In high‑traffic public restrooms, the steel frame with 2.0 mm base rail resists impact from equipment, and the adjustable feet maintain alignment on uneven tile substrates.
Customization
Dimensions can be adjusted in width, depth, and height to suit specific rough‑in requirements. Drawer interiors can be fitted with dividers, trays, or liners made from PVC or recycled polypropylene.
Hardware options include soft‑close dampers, push‑to‑open mechanisms, or lockable draws.
Cut‑outs for plumbing or electrical services are provided as per CAD files supplied by the customer, with reinforced edges to maintain structural integrity.
Quality Control
Each unit undergoes visual inspection for weld continuity, coating uniformity, and dimensional accuracy using calibrated fixtures. Functional testing includes drawer cycle operation (5,000 cycles) and load verification.
Final inspection records are retained and can be provided upon request, ensuring traceability for audit purposes.
Packaging and Shipping
- Components are nested in recyclable corrugated cartons with internal PE foam protection for corners and edges.
- Palletized loads include corner boards and stretch film to prevent shifting during transit.
- Export shipments comply with ISPM‑15 wood‑free packaging standards.
FAQ
- Can the vanity dimensions be customized?
- Yes. Width, depth, and height can be adjusted in 50 mm increments based on project requirements. Custom sizes are quoted after receipt of detailed drawings.
- What information is needed for a quotation?
- Required inputs include overall dimensions, drawer/door configuration, material choice (steel type and finish), any cut‑outs for services, and required quantity.
- What material options are available for corrosive environments?
- Stainless steel 304 or 316 frames with either a brushed finish or a protective powder coat are available upon request.
- How is the product inspected before shipment?
- Each unit receives a 100 % visual weld and coating check, followed by functional tests of drawer slides and load capacity. Inspection reports are available on request.
- What packaging methods are used for overseas shipments?
- Units are packed in foam‑lined cartons, palletized, and wrapped with stretch film. All packaging is ISPM‑15 compliant.
