Direct Factory Oval Bathroom Mirror Cabinet

An oval bathroom mirror cabinet combines a reflective surface with enclosed storage, designed for environments where space efficiency and moisture resistance are critical. The geometry eliminates sharp corners, reducing impact risk in high‑traffic commercial restrooms while providing a ergonomic profile for users of varying heights.

Design and Geometry

The cabinet features a true oval footprint with a major axis typically ranging from 600 mm to 900 mm and a minor axis from 400 mm to 600 mm, depending on the model. Frame depth is kept uniform at 20 mm to maintain a low profile, while the door swing radius is limited to 150 mm to avoid interference with adjacent fixtures.

Material Construction

Primary structural members are formed from 1.2 mm thick ASTM A240 304 stainless steel, offering a yield strength of approximately 215 MPa and a corrosion resistance suitable for chloride‑laden atmospheres. The mirror substrate is 5 mm float glass with a silver‑aluminum backing, providing a reflectance of 85 %+ across the visible spectrum and a surface flatness tolerance of ±0.1 mm per meter.

Mounting and Installation

Installation utilizes four concealed M6 stainless steel anchors rated for a shear load of 1.5 kN each, allowing a total cabinet weight capacity of up to 30 kg when mounted on solid concrete or masonry. For stud‑wall applications, a backing plate distributes load over a minimum of two studs, reducing point stress to below 0.8 kN per fastener.

Environmental Resistance

The assembly achieves an IP44 rating, protecting against splashing water from any direction and solid objects larger than 1 mm. Accelerated salt‑spray testing (ASTM B117) shows no visible corrosion after 500 hours at 5 % NaCl solution, confirming suitability for coastal or high‑humidity facilities such as spas and locker rooms.

Customization Options

• Overall dimensions adjustable in 50 mm increments along each axis
• Frame finish options: brushed satin, powder‑coated RAL colors, or PVD titanium gold
• Integrated LED edge lighting with selectable color temperature (3000K‑6000K) and dimming via 0‑10 V
• Anti‑fog coating applied to the mirror surface, reducing condensation thickness by up to 70 % at 40 °C
• Internal shelving configurations: fixed glass, adjustable metal, or removable polymer trays

Quality Assurance

Each unit undergoes a three‑stage inspection: dimensional verification using CMM with ±0.05 mm repeatability, reflectance measurement via spectrophotometer to confirm >84 % average, and functional testing of door hinges for 20 000 cycles without deviation beyond 2° angular drift. Documentation includes material certificates, test reports, and a traceability label affixed to the rear panel.

Applications

In hospitality settings, the oval profile minimizes protrusion into circulation paths, allowing tighter vanity layouts without compromising ADA clearance. Healthcare facilities benefit from the seamless, crevice‑free interior that simplifies disinfection protocols, while the corrosion‑resistant frame withstands frequent exposure to cleaning agents and sterilizing vapors.

Packaging and Shipping

Units are packed in double‑wall corrugated cartons with internal corner protectors and a polyethylene moisture barrier. Each carton includes a custom‑cut foam cradle that immobilizes the cabinet, limiting shock transmission to below 15 g during transit. Palletized loads utilize stretch film and edge boards, allowing safe stacking of up to three layers for full‑truckload shipments.
