China Over Toilet Cabinet Wall Mount

This wall‑mounted storage unit is designed to fit directly above a standard toilet tank, utilizing otherwise unused vertical space in commercial restrooms, healthcare facilities, and industrial washrooms. The cabinet is secured to the wall studs or solid masonry using heavy‑duty brackets, providing a stable platform for toiletries, cleaning supplies, or personal items while keeping the floor area clear for traffic and maintenance equipment.

Key Technical Features

• Constructed from 1.2 mm cold‑rolled steel sheet with a powder‑coat finish, offering a typical corrosion resistance of 500 hours salt spray per ASTM B117.
• Internal dimensions: 350 mm W × 150 mm D × 300 mm H (customizable in 25 mm increments).
• Load rating: 25 kg uniformly distributed across the shelf, tested to EN 14749‑2 safety standards.
• Mounting system includes four M8 × 80 mm galvanized steel anchors with optional vibration‑isolating rubber washers.
• Door configuration: single‑panel swing with 110° opening angle, concealed hinge, and magnetic catch.

Typical Specifications

Applications and Suitability

In high‑traffic environments such as airports, factories, and hospitals, floor space is often at a premium. Mounting a cabinet above the toilet eliminates the need for freestanding units that can obstruct cleaning carts or impede wheelchair access. The steel construction resists impacts from maintenance equipment, while the powder‑coat surface withstands frequent disinfection with alcohol‑based or chlorine‑based agents without degradation.

The product is also suited for temporary installations in construction site offices or modular housing units, where the anchoring system can be adapted to metal studs or concrete inserts. Because the load rating is well below the typical capacity of standard wall studs (≈150 kg), the mounting hardware provides a generous safety factor for dynamic loads caused by door opening and closing.

Installation Overview

1. Locate wall studs or prepare solid masonry anchors at the desired height (typically 1200 mm above finished floor).
2. Drill pilot holes matching the M8 anchor diameter (10 mm) and insert the supplied galvanized anchors.
3. Attach the mounting brackets using the provided washers and nuts, torque to 15 Nm.
4. Hang the cabinet onto the brackets, verify level, and secure the anti‑tamper set screws.
5. Install the door, adjust hinge tension if needed, and confirm magnetic catch engagement.

Quality Assurance

Each unit undergoes a three‑stage inspection: dimensional verification using calibrated calipers (±0.1 mm tolerance), coating thickness measurement via magnetic induction (target 60 µm ±10 µm), and load testing where a 25 kg weight is applied for 5 minutes with no permanent deformation observed. Records are retained for traceability and are available upon request.

Customization Options

Dimensions can be adjusted in 25 mm steps to accommodate non‑standard toilet layouts or specific storage requirements. Alternative materials such as stainless steel grade 304 are available for environments requiring higher chemical resistance. Finish options include antimicrobial powder coat or brushed stainless steel for aesthetic integration with premium fixtures. Hardware selections can include tamper‑proof screws or quick‑release brackets for maintenance‑friendly designs.

Call to Action

For detailed drawings, material certifications, or a project‑specific quotation, please contact our technical sales team. Provide the intended mounting surface, required internal dimensions, and any environmental constraints to receive a tailored solution.
