Free Standing Single Bathroom Vanity with Sink – China Manufactured

The vanity combines a freestanding cabinet with an integrated single basin to provide a compact washing station suitable for residential bathrooms, hotel guest rooms, and small commercial facilities.

Material Selection

Cabinet panels are manufactured from moisture-resistant medium-density fiberboard (MDF) with a sealed PVC laminate surface, offering a board density of approximately 650 kg/m³ and a thickness of 18 mm for sidewalls and 25 mm for the top.

Sink Configuration

The basin is formed from vitreous china, fired at 1240 °C to achieve low water absorption (<0.5 %) and a glossy finish that resists staining and chemical attack from common bathroom cleaners.

Overall Dimensions and Ergonomics

Standard overall dimensions are 600 mm wide, 460 mm deep, and 850 mm high, including the countertop thickness, providing a comfortable working height for most users.

• Width: 600 mm (customizable in 50 mm increments)
• Depth: 460 mm (standard)
• Height: 850 mm (including 25 mm top)
• Weight: approximately 22 kg (depending on finish)
• Load capacity: tested to 150 kg static weight on the countertop

Installation Requirements

Installation requires a level floor and provision for hot and cold water supply lines within 150 mm of the faucet mounting holes, plus a drain outlet positioned 200 mm from the rear edge of the cabinet.

Quality Assurance

Each unit undergoes dimensional inspection using a coordinate measuring machine with a tolerance of ±0.5 mm on critical faces, and the laminate surface is subjected to a cross‑hatch adhesion test (ASTM D3359) to ensure coating integrity.

Customization Options

Customization options include alternative widths from 500 mm to 800 mm in 50 mm increments, and a choice of three laminate finishes: white, light gray, and natural oak.

Parameter	Typical Value	Notes
Cabinet width	600 mm	Adjustable ±50 mm
Countertop thickness	25 mm	Includes laminate and substrate
Basin depth	180 mm	From countertop to lowest point
Water absorption (china)	<0.5 %	Measured per ISO 10545-3
Load capacity	150 kg	Static, evenly distributed

Typical Applications

The freestanding configuration simplifies retrofit in existing bathrooms where wall mounting is impractical due to structural limitations, and the integrated sink eliminates the need for separate countertop fabrication.

Frequently Asked Questions

Buyers often inquire about lead time, sample availability, and packaging methods for overseas shipment.

• Can dimensions be customized? Yes, width can be adjusted in 50 mm steps; depth and height are fixed unless a special quote is requested.
• What information is required before quotation? Project dimensions, desired finish, faucet hole configuration, and quantity.
• What materials are available? Moisture‑resistant MDF with PVC laminate for the cabinet; vitreous china for the basin; optional stainless‑steel legs.
• How is quality inspected? Dimensional checks, adhesion testing, and water‑tightness of the basin before packaging.
• What packaging methods are available? Each unit is packed in a five‑wall corrugated carton with corner protectors and placed on a pallet for sea freight.
• How are export shipments protected? Cartons are wrapped in stretch film and sealed with moisture‑resistant tape; pallets are strapped and labeled with handling instructions.
• What is the typical production lead time? 20‑25 working days after receipt of deposit and final drawings.
• How are samples arranged? Samples can be shipped via express courier; the cost is credited against the first order.

Contact for Quotation

To obtain a detailed quotation or discuss project‑specific requirements, please contact our sales team.

Request a quotation
